Product Details

General Information

Machine Type

• A3 Colour Laser Multifunctional

Core Functions

• Print, Copy, Scan, Send, Store and Optional Fax

Processor Speed

• 1.8GHz Dual Core Processor

Control Panel

• 10.1 inch TFT LCD WSVGA Colour Touch panel

Memory

• Standard: 5.0 GB RAM
• Main CPU Side: 2 GB
• Image Processing CPU Side: 2 GB + 1 GB (reserved for image processing)

Storage

• Standard: (SSD) 256 GB
• GB Optional: (SSD) 1 TB

Interface Connection

Network:

• Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN(IEEE 802.11 b/g/n)
• Optional: Bluetooth Low Energy

Others:

• Standard: USB 2.0(Host) x1, USB 3.0(Host) x1, USB 2.0(Device) x1
• Optional: Serial Interface, Copy Control Interface

Network Protocols

• TCP/IP (FTP, SMTP, POP, HTTP, SNMP, LDAP, SLP, SMB, LPD, IPP, WS-Discovery, Bonjour, Direct Mobile Printing, Port9100, SNTP, 802.1X, DHCP, DNS, NTP)

Paper Supply Capacity (A4, 80 gsm)

• Standard: 3,550 sheets
• 250-sheet Multi-purpose Tray, 1,100-sheet Paper Deck x 2, 550-sheet Paper Cassette x 2
• Maximum: 7,050 sheets (with POD DECK LITE-C1 or PAPER DECK UNIT-E1)

Paper Output Capacity (A4, 80 gsm)

• 250 sheets (with Copy Tray-R2)
• Maximum: 3,500 Sheets (with Staple Finisher-AC1 or Booklet Finisher-AC2)
• Maximum: 5,000 Sheets (with Staple Finisher-AG1 or Booklet Finisher-AG1)

Finishing Capabilities

• With options: Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand, Document Insertion, Z-fold, Half-fold, C-fold, Accordion-Z fold, Double Parallel-fold, Trimming

Supported Media Types

• Multi-purpose tray: Thin, Plain, Recycled, Colour, Heavy, Coated, Textured, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope
• Paper Decks (Right/Left): Thin, Plain, Recycled, Colour, Heavy, Tracing, Bond, Transparency, Bond, Pre-punched, Letterhead
• Paper Cassettes (Upper/Lower): Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead, Tab*1, Envelope*2

*1 Tab Feeding Attachment-F1 is required
*2 Envelope Feeder Attachment-F1 is required.

Supported Media Sizes

Multi-Purpose Tray:

• Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
• Custom size: 90.0 x 148.0mm to 330.2 x 487.7mm
• Long size: 210 x 487.8mm to 330.2 x 1,300mm*1
• Free size: 100.0 x 148.0 mm to 330.2 x 487.7 mm
• Envelope: COM10 No.10, Monarch, DL, ISO-C5
• Envelope custom size: 90.0 x 148 mm to 330.2 x 487.7 mm

*1 by service mode

Paper Decks (Right/Left):

• Standard size: A4, B5

Paper Cassettes (Upper/ Lower):

• Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
• Custom size: 139.7 x 182mm to 330.2 x 487.7mm
• Envelope: COM10 No.10, Monarch, DL, ISO-C5
• Envelope custom size: 98.0 x 148mm to 330.2 x 487.7mm

Supported Media Weights

• Multi-purpose tray: 52 to 350 gsm
• Paper Deck (Right/Left): 52 to 220 gsm
• Paper Cassette (Upper/Lower): 52 to 256 gsm
• Duplex: 52 to 220 gsm

Warm-up Time

• Quick Startup Mode: 4 seconds or less (Time until key operations can be performed on the touch panel display)
• From Power On: 30 seconds or less (Time until it becomes possible to start copying)
• From Sleep Mode: 30 seconds or less

Dimensions (W x D x H)

• 689 x 937 x 1,185mm

Warm-up Time

• 7 minutes from power-on to copy-ready status

Installation Space (W x D)

• Basic: 2,026 x 1,524mm (with front door open + multi-purpose tray/upper-right cover open + buffer pass-M1 + booklet finisher-AC2/extension tray & rotary tray extended)

Weight

• Approx. 261kg (including toner)

Print Specifications

Printing Method

• Colour Laser Beam Printing (Electronic Photography)

Colour Laser Beam Printing (Electronic Photography)

• Up to 70/80 ppm (A4, Colour/BW)

Alignment Tolerance

• Cross track: 2.0mm or less, In track: 1.2mm or less

Print Resolution (dpi)

• 2,400 x 2,400

Page Description Languages

• UFR II, PCL6, (optional) imagePRESS PS Printer Kit-G1

Direct Print

• Direct printing available from USB memory, Advanced Space, Remote UI and Web Access*
• Supported file types: TIFF, JPEG, PDF, EPS and XPS

*Only PDF print from websites is supported

Mobile / Cloud Printing

• AirPrint, Mopria, Canon PRINT Business, uniFLOW Online and Universal Print
• A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements. Please contact your sales representative for further information.

OS Standard Printing

• Android/Windows® 10/Chrome OS/macOS (11.2.2) /iOS/iPadOS (As of Mar. 2021)

Fonts

• PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé
• Mono WT J/K/S/T* (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts**

* Requires optional PCL INTERNATIONAL FONT SET-A1
**Require optional BARCODE PRINTING KIT-D1

Print Features

• Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/ Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer

Operating Systems

• UFRII: Windows® 8.1/10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022, Mac OS X (10.11 or later)
• PCL: Windows® 8.1/10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022
• PS: Windows® 8.1/10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022, Mac OS X (10.11 or later)
• PPD: Windows® 8.1/10/11, Mac OS X(10.11 or later)

Copy Specifications

Copy Speed

• 70 ppm CL and 80 ppm BW (A4, A5*, A5R, A6R*)
• 35 ppm CL and 40 ppm BW (A3)
• 49 ppm CL and 56 ppm BW (A4R)

*1-sided

First-Copy-Out Time

• Approx. 4.4/5.4 seconds or less

Copy Resolution (dpi)

• 600 x 600

Multiple Copies

• Up to 9,999 copies

Copy Density

• Automatic or Manual (9 Levels)

Magnification

• 25% – 400% (1% Increments)

Preset Reductions

• 25%, 50%, 70%, 100% (1:1)

Preset Enlargements

• 141%, 200%, 400%

Scan Specifications

Type

• Single-pass Duplexing Automatic Document Feeder* [2-sided to 2-sided (Automatic)]

* Detect Feeder Multi Sheet Feed is supported.

Pull Scan Specifications

• Colour Network ScanGear2. For both TWAIN and WIA
• Supported OS: Windows® 8.1/10/11/Server2012/Server2012 R2/Server 2016/Server 2019/Server 2022 (As of Nov. 2021)

Scan Resolution (dpi)

• Scan for Copy: 600 x 600dpi
• Scan for Send: (Push) 600 x 600dpi (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600dpi
• Scan for Fax: 600 x 600dpi

Document Feeder Paper Capacity (80 gsm)

• up to 200 Sheets

Acceptable Originals/Weights

• Platen: Sheet, Book, and 3-Dimensional objects

Document Feeder Media Weight:

• 1-sided scanning: 38 to 220 gsm (BW, CL)
• 2-sided scanning: 38 to 220 gsm (BW, CL)

*An acceptable weights of A6R or smaller is 50 to 220 gsm

Supported Media Sizes

• Platen: max. scanning size up to 297.0 x 431.8mm
• Document feeder media size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6R
• Custom size: 70.0 x 139.7mm to 304.8 x 431.8mm

Scan Method

• Push Scan, Pull Scan, Scan to Box, Scan to Advanced Space, Scan to Network, Scan to USB Memory Key, Scan to Mobile device, Scan to cloud (uniFLOW Online optional)

Scan Speed

• Single-sided Scanning: 135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy)

Double-Sided Scanning

• Double-sided Scanning: 270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy)

Send Specifications

Destination

• E-mail/Internet FAX (SMTP), SMB v3.0, FTP, WebDAV, Mail Box, Super G3 FAX (Optional), IP Fax (Optional)

Address Book / Speed Dials

• LDAP (2,000), Local (1,600), Speed dial (200)

Send Resolution (dpi)

• 600 x 600

Communication Protocol

• File: FTP (TCP/IP), SMB v3.0, WebDAV
• E-mail/I-Fax: SMTP, POP3

File Format

• TIFF, JPEG, PDF(Compact, Searchable, Apply policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

Universal Send Features

• Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Copy Ratio, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Pages

Fax Specifications

Optional / Standard

• Optional

Maximum Number of Connection Lines

• 1

Modem Speed

• Super G3: 33.6 kbps
• G3: 14.4 kbps

Compression Method

• MH, MR, MMR, JBIG

Resolution (dpi)

• 400 x 400dpi (Ultra Fine), 200 x 400dpi (Super Fine), 200 x 200dpi (Fine), 200 x 100dpi (Normal)

Sending/Receiving Size

• Sending: A3, A4, A4R, A5*1, A5R*1, B4, B5*2, B5R*1
• Receiving: A3, B4, A4, A4R, A5R , B5, B5R

*1 Sent as A4
*2 Sent as B4 short

FAX Memory

• Up to 30,000 pages (2,000 jobs)

Speed Dials

• Max. 200

Group Dials/Destinations

• Max. 199 dials

Sequential Broadcast

• Max. 256 addresses

Memory Backup

• Yes

Fax Features

• Sender’s Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log

Store Specifications

Mail Box

• 100 User Inboxes, 1 Memory RX Inbox, 50 Confidential Fax Inboxes
• Maximum 30,000 Pages (2,000 jobs) Stored

Advanced Space

• Communication Protocol: SMB or WebDAV
• Supported Client PC: Windows® 8.1/10
• Concurrent Connections (Max.): SMB:64, WebDAV:3

Advanced Space Available Disk Space

• Approx. 16 GB
• Approx. 480 GB (with optional)

Advanced Space Features

• Authentication for Advanced Space Log-in, Sort Function, Printing a PDF File with a Password, imageWARE Secure Audit Manager Support, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore

Security Specifications

Authentication & Access Control

• User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)

Network Security

• TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/ Wired LAN), Disabling Unused Functions (Enabling/ Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception

Document Security

• Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*1), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Space Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/ Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark) *1 Requires uniFLOW Online / uniFLOW

Authentication & Access Control

• User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)

Device Security

• Protecting SSD Data [SSD Data Encryption (FIPS140-2 Validated), SSD Lock], Standard SSD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFP Software Integrity (Verify System at Startup, Runtime Intrusion Detection), Common Criteria Certification (HCD-PP: pending confirmation)

Device Management & Auditing

• Administrator Password, Digital Certificate And Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Environmental Specifications

Operating Environment

• Temperature: 20-27 0C
• Humidity: 15-60 % RH (Relative Humidity without condensation)

Power Source

• 220-240 V (±10 %), 50/60 Hz (±2 Hz), 10 Amp

Power Consumption

• Approx. 2,000 W
• Copying: (with DADF continuous scan) Approx. 1,228 W*1
• Standby: Approx. 136.6 W*1
• Sleep mode: Approx. 0.9 W*2
• Typical Electricity Consumption (TEC): 1.16 kWh
• Note: As per USA Energy Star 3.0

Noise Levels

• Active (BW) (1-sided): 7.0 B*, Kv 0.3 B*

• Active (BW/CL) (1-sided): 55 dB*/55 dB*
• Stand-by: 35 dB*

Standards

• Blue Angel

Software & Printer Management

Tracking & Reporting

• Universal Login Manager (ULM)

Remote Management Tools

• iWEMC (iW Enterprise Management Console)
• eMaintenance
• Content Delivery System

Scanning Software

• Color Network ScanGear 2

Optimisation Tools

• Canon Driver Configuration Tool

Platform

• MEAP (Multifunctional Embedded Application Platform)

Fiery Print Controller Specifications

Optional/Standard

• Optional

Name

• imagePRESS Server M20 (Embedded)

Print Resolution (dpi)

• 1200 x 1200, 600 x 600

Page Description Language(s)

• Adobe PS3, PCL6

Memory

• 8 GB (2 x 4 GB)

Hard Disk Drive

• 500 GB SATA

Processor Speed

• Intel Pentium G5400 (3.7 GHz)

System

• Fiery FS500

Fonts

• PS: 138 Fonts
• PCL: 113 Fonts

Supported Operating Systems

• Windows® 7 64 bit/Windows 8.1 64 bit/Windows10 64 bit/Windows11/Windows Server 2008 R2 64bit only/Windows
• Server 2012 64bit only/ Windows Server 2012 R2 64bit only/Windows Server 2016 64bit/Windows Server 2019 64bit/Windows Server 2022 64bit/ MAC OS (10.14, 10.15, 11.0, 12)

Interface

• 2 x Ethernet (1000Base-T/100Base-TX/10Base-T), USB3.0 x 2 (Rear), USB2.0 x 4 (Rear)

Network Protocols

• TCP/IP (FTP, SMTP, POP, HTTP, SNMP, LDAP, SLP, SMB, LPD, IPP, WS-Discovery, Bonjour, Direct Mobile Printing, Port9100, SNTP, 802.1X, DHCP, DNS, NTP)

Direct Print

• PDF1.7, EPS, TIFF6, JDF1.4/JMF (Optional)

VDP

• FreeForm v1/v2.1

Fiery Print Controller Standard Features

• Fiery Command WorkStation6 / Paper Catalog / Fiery Spot-On / Fiery Remote Scan / Fiery Hot Folders & Virtual Printers

Fiery Print Controller Options

• Fiery Impose / Fiery Compose / Fiery Impose and Compose / Fiery Job Expert and PDF Processing Kit

HW Platform

• E500

Base Operating System

• Debian of Linux

Power Source

• AC100-240V, 50HZ/60HZ, 3.0A (100V) – 1.3A (240V)

Maximum Power Consumption

• 55 W

Dimensions (W x D x H)

• 297 x 90 x 272 mm

Weight

• Fiery unit only (with plate): Approx. 5.5 kg

Consumables

Toner Cartridge/s

• Toner T07 BK/C/M/Y

Toner Estimated Yield

• Toner T07 BK: 54,500 pages
• Toner T07 C/M/Y: 37,500 pages

Paper Supply Options

Paper Deck

POD Deck Lite-C1:

• Paper Capacity: 3,500 sheets (80 gsm)
• Paper Type: Thin, Plain, Recycled, Thick, Colour, Pre-punched, Letterhead, Bond, Tab, Transparency, Label, Coated, Textured, Tracing, Envelope*
• Paper Size: A3, B4, A4, A4R, B5, B5R, A5R, SRA3, 11”x17”, LGL_R, LTR, LTR_R, EXE, STMT_R, 12”x18”, 13”x19”, 8K, 16K, 16K_R, Envelope [No.10(COM10), Monarch, DL, ISO-C5], Custom size (139.7 x 148.0 mm to 330.2 x 487.7 mm)
• Paper Weight: 52-350 gsm
• Power Source: 220-240V, 50/60Hz, 1.2A
• Dimensions (W x D x H): 633 x 686 x 574 mm (attached to the main unit) Weight: Approx. 68 kg

*Requires ENVELOPE FEEDER ATTACHMENT-G1

Paper Deck Unit-E1:

• Paper Capacity: 3,500 sheets (80 gsm)
• Paper Type: Thin, Plain, Recycled, Thick, Colour, Pre-punched, Letterhead, Bond
• Paper Size: A4, B5, LTR*
• Paper Weight: 52-256 gsm
• Power Source: From the main unit
• Dimensions (W x D x H): 340 x 630 x 572 mm (attached to the main unit) Weight: Approx. 34 kg

*Media size change requires service technicians

Output Options

Copy Tray

Copy Tray-R2:

• Provides a simple tray for basic output needs.
• Capacity: 250/100 sheets (1-sided/2-sided, 80 gsm)

Staple Finisher

Staple Finisher-AC1:

Tray Capacity (with 80gsm paper):

• Upper Tray: A4, A5, A5R, A6R, B5: 250 sheets SRA3, A3, A4R, B4, B5R: 125 sheets Envelope: 30 sheets;
• Mid Tray: Same as upper tray
• Lower Tray: A4, A5, A5R, B5: 3,000 sheets; SRA3, A3, A4R, B4, B5R: 1,500 sheets; A6R: 250 sheets; Envelope: Monarch: 30 sheets;  COM10 No.10, DL, ISO-C5: 100 sheets
• Paper Weight: Upper Tray: 52 to 256 gsm; Mid Tray: same as Upper tray; Lower Tray: 52 to 350 gsm
• Staple Position: Corner, Double
• Staple Capacity: A4/B5: 65 sheets (52 to 90 gsm);A3/A4R/B4: 40 sheets (52 to 90 gsm)
  Eco Staple: A3/A4: 10 sheets (52 to 64 gsm); 8 sheets (65 to 81.4 gsm); 6 sheets (82 to 105 gsm)
• Staple On Demand: 65 sheets (52 to 90 gsm)
• Power supply: From the main unit
• Dimensions (W x D x H): 656 × 623 × 1,195 mm (when the extension tray and rotary tray are extended)
• Weight: Approx. 36 kg



Staple Finisher-AG1 (Requires the Accessory Interface Kit-A2):

Tray Capacity (with 80gsm paper):

• Upper Tray: SRA3, A3, A4, A4R, A5R, A5, A6R, B4, B5, B5R: 1,000 sheets (64 to 324gsm); 200 sheets (325 to 350gsm)
• Lower Tray: A4, B5: 2,000 sheets(64 to 324gsm), 400 sheets (325 to 350gsm); SRA3, A3, A4R, B4 : 1,000 sheets(64 to 324gsm), 200 sheets (325 to 350gsm); B5R: 1,000 sheets(64 to 324gsm), 400 sheets (325 to 350gsm)
• Lower Tray (High capacity loading mode): A4, B5: 4,000 sheets; A4R, B5R : 2,000 sheets; A3, B4 : 1,500 sheets; SRA3: 1,000 sheets
• Paper Weight: 52 to 350 gsm
• Staple Position: Corner, Double
• Staple Capacity (including Staple On Demand): A4/B5: 100 sheets (52 to 80 gsm); A3/A4R/B4/B5R: 50 sheets (52 to 81.4 gsm)
• Power supply: 220-240V/8A 50/60Hz
• Dimensions (W x D x H): 860 × 792 × 1,239 mm (when the extension tray is extended)
  Weight: Approx. 130 kg

Booklet Finisher

Paper Folding

Paper Folding Unit-K1 (Requires either the Staple Finisher-AG1 or Booklet Finisher-AG1):

• Supported Folding Type: Z-Fold, C-Fold, Accordion-Z-Fold, Double Parallel-Fold, Half-Fold
• Acceptable Paper Type: Thin, Plain, Recycled, Colour, Bond
• Acceptable Paper Sizes: Z-Fold: Thin, Plain, Recycled, Color: A3,A4R,B4, C-Fold/Accordion-Z-Fold/Double Parallel Fold/Half-Fold: A4R
• Acceptable Paper Weight: Z-Fold/ C-Fold/Accordion-Z-Fold/Half-Fold: 52 to 105 gsm, Double Parallel-Fold: 52 to 90 gsm
• Power Source: from the finisher
• Dimensions (W x D x H): 336 × 793 × 1,190 mm (attached to the device)
• Weight: Approx. 71 kg

Document Insertion

Document Insertion Unit-R1 (Requires either the Staple Finisher-AG1 or Booklet Finisher-AG1):

• Number of trays: 2
• Tray Capacity: Up to 100 Sheets (with 80 gsm paper)
• Upper tray: up to 200 sheets
• Lower tray: up to 200 sheets
• Acceptable Paper Type: Thin, Plain, Recycled, Color, Heavy, Coated, Textured, Bond, Pre-punched, Letterhead, Tab
• Acceptable Paper Sizes: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
• Acceptable Paper Weight: 52 to 300 gsm
• Power Source: 100-240V/50/60Hz 1.0A
• Dimensions (W x D x H): 336× 793 × 1,407 mm (attached to the device: width excluding document tray)
• Weight: Approx. 61 kg

Document Insertion/Folding Unit-K1 (Requires either the Staple Finisher-AC1 or Booklet Finisher-AC2):

• Number of trays: 1
• Supported Folding Type: Z-Fold, C-Fold
• Acceptable Paper Type: Insertion Unit: Thin, Plain, Recycled, Colour, Heavy, Coated, Textured, Bond, Letterhead, Tab; Z-Fold/C-Fold: Thin, Plain, Recycled, Colour
• Acceptable Paper Sizes: Insertion Unit: SRA3, A3, A4, A4R, B4, B5, B5R; Z-Fold: A3, A4R, B4; C-Fold: A4R
  Acceptable Paper Weight: Insertion Unit: 60 to 256 gsm; Z-Fold/C-Fold: 60 to 105 gsm
• Tray Capacity (with 80 gsm paper): Insertion: Up to 100 Sheets; Z-Fold*: A3, B4: 30 sheets; A4R: 10 sheets; C-fold: A4R: 40 sheets
• Power Source: 100-240V/50/60Hz 1.0A
• Dimensions (W x D x H): 247 × 679 × 1,242 mm (attached to the device: width excluding document tray)
• Weight: Approx. 76 kg

*Z-Fold output to the Staple Finisher-AC1 or Booklet Finisher-AC2

Hole Puncher

4 Hole Puncher Unit-A1 (Requires either the STAPLE FINISHER-AC1 or BOOKLET FINISHER-AC2):

• 4 Holes (SWE)
• Paper Weight: 52-300 gsm
• Paper Size: A3, A4, A4R, B4, B5, B5R
• Power Source: from the finisher

Puncher Unit-BT1 (2/F4H) (Requires either the STAPLE FINISHER-AG1 or BOOKLET FINISHER-AG1):

• 2 or 4 Holes (FRN)
• Paper Weight: 52-300 gsm
• Paper Size: 2 holes A3, A4, A4R, A5L, B4, B5, B5R, Custom size (182 x 182 mm to 297 x 432.0 mm excluding 203 x 257
  mm to 297 x 270 mm); 4 holes A3, A4, B4, B5, Custom size (257 x 182 mm to 297 x 432 mm)
• Power Source: from the finisher

Puncher Unit-BU1 (S4H) (Requires either the STAPLE FINISHER-AG1 or BOOKLET FINISHER-AG1):

• 4 Holes (SWE)
• Paper Weight: 52-300 gsm
• Paper Size: A3, A4, A5L, B4, B5, Custom size (257 x 182mm to 297 x 432 mm)
• Power Source: from the finisher

2/4 Hole Puncher Unit-A1 (Requires either the Staple Finisher-AC1 or Booklet Finisher-AC1):

• Two or Four Holes
• Acceptable Punch Paper Weight: 52 to 300 gsm
• Acceptable Punch Paper Size: Two holes A3, A4, A4R, A5, B4, B5, B5R; Four holes A3, A4
• Power Source: from the finisher

Booklet Trimmer-G1 (Requires Booklet Finisher-AG1):

• Acceptable Paper Size: Standard size: SRA3, A3, A4R, B4
• Custom size: 210.0×279.4 mm to 330.2×487.7 mm
• Waste Tray Capacity: approx. 5,000 sheets
• Acceptable Paper Weight: 52 to 220 gsm
• Trim Amount: 2 to 28mm
• Power Source: from the finisher
• Dimensions (W x D x H): 1,933 × 794 × 1,044 mm (attached to the device: width excluding belt conveyer)
• Weight: Approx. 152 kg

Hardware Accessories

Card Readers

• Copy Card Reader-F1
• Copy Card Reader Attachment-A4

Others

• Utility Tray-B1
• Printer Cover-h3
• Tab Feeding Attachment-F1
• Numeric Keypad-A2
• Accessory Interface Kit-A2
• Finisher Jogger Kit-A1
• Side Guide Plate Fixing Bracket-A1
• Envelope Feeder Attachment-H1
• Envelope Feeder Attachment-F1
• Envelope Feeder Attachment-G1
• Stack Bypass Alignment Tray-D1
• Long Sheet Tray-B1
• Paper Deck Path Kit-B1
• Finisher Long Sheet Catch Tray-B1
• Inserter Option controller Kit-A1
• Antimicrobial Film
• Copy Card Reader Attachment-A5

Security Options

Data Security

• Memory Mirroring Kit-A1
• 1TB SSD-A1
• 250GB SSD-A1 (usage with Memory Mirroring Kit-A1)

System & Controller Options

Print Accessories

• PCL International Font Set-A1
• imagePRESS PS Printer Kit-G1

Communication Protocol

• File: FTP (TCP/IP), SMB v3.0, WebDAV
• E-mail/I-Fax: SMTP, POP3

Barcode Printing

• Barcode Printing Kit-D1

EFI-Fiery Based Controller

• imagePRESS Server M20

EFI-Fiery Based Controller Options

• Fiery Impose
• Fiery Compose
• Fiery Impose and Compose

System Accessories

• Copy Control Interface Kit-A1
• Connection Kit-A4 for Bluetooth LE
• Serial Interface Kit-K3

Fax Accessories

• Super G3 FAX Board-AX1
• Remote Fax Kit-A1
• IP FAX Expansion Kit-B1

Other Options

Staple Cartridge

• Staple-N1, Staple-P1, Staple Cartridge-X1, Staple Cartridge-Y1

Accessibility Accessories

• ADF Access Handle-A1
• Voice Guidance Kit-G1
• Voice Operation Kit-D1
