Product Details

Main Unit

Machine Type

• A3 Monochrome Laser Multifunctional

Core Functions

• Print, Copy, Scan, Send, Store and Optional Fax

Processor Speed

• 1.8GHz Dual Core Processor

Control Panel

• 10.1″ TFT LCD WSVGA Colour Touch Panel

Memory

• Standard: 6.0 GB RAM

Storage

• Standard: (SSD) 256 GB
• Optional: (SSD) 1 TB

Interface Connection

Network:

• Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)
• Optional: Bluetooth Low Energy

Others:

•   Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1
•   Optional: Serial Interface, Copy Control Interface

Paper Supply Capacity (A4, 80 gsm)

• Standard: 1,200 sheets, 100-sheet multi-purpose tray x 1, 550-sheet paper cassettes x 2
• Maximum: 6,350 sheets (with High Capacity Cassette Feeding Unit-C1 + Paper Deck Unit-F1)

Paper Output Capacity (A4, 80 gsm)

• Maximum: 3,450 sheets (with Staple Finisher-AB2 or Paper Folding/Booklet Finisher-A1 and 3rd Copy Tray Kit-A1)

Finishing Capabilities

• Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand, V-fold, C-fold, Z-fold

* Finishing capabilities vary depending on the options connected.

Supported Media Types

• Multi-purpose tray: Thin, Plain, Recycled, Colour, Heavy, Coated, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope
• Paper cassette (upper/lower): Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead, Envelope*

* Envelope Feeder Attachment (standard) is required.

Supported Media Sizes

Multi-Purpose Tray:

• Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
• Custom size: 98.0 x 139.7mm to 320.0 x 457.2mm
• Free size: 98.0 x 139.7mm to 320.0 x 457.2mm
• Envelopes: COM 10 No.10, Monarch, DL, ISO-C5
• Envelope custom size: 98.0 x 90.0mm to 320.0 x 457.2mm

Upper Cassette:

• Standard size: A4, A5, A5R, A6R, B5
• Custom size: 98.0 x 148.0mm to 297.0 x 215.9mm
• Envelopes: COM10 No.10, Monarch, DL, ISO-C5

Lower Cassette:

• Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
• Custom size: 98.0 x 148.0mm to 304.8 x 457.2mm
• Envelopes: COM10 No.10, Monarch, DL, ISO-C5

Supported Media Weights

• Multi-purpose tray: 52 to 300 gsm
• Paper cassettes (upper/lower): 52 to 256 gsm
• Duplex: 52 to 256 gsm

Warm-up Time

• Quick Startup Mode: 4 Seconds or less*
• From Sleep Mode: 6 Seconds or Less
• From Power On: 6 Seconds or less*

* Time from device power-on to when the copy icon appears and is enabled to operate on the touch panel display.

*Time from device power-on, until copy ready (not print reservation).

Dimensions (W x D x H)

• 620 x 722 x 937mm

Installation Space (W x D)

• Basic: 1,138 x 1,162mm (right cover open with multi-purpose tray extended + cassette drawers open)
• Fully Configured: 1,866 x 1,162mm (Staple Finisher-AB2+ Paper Folding/Booklet Finisher-A1 with the extension tray extended + Paper Deck Unit-F1 + cassette drawers open)

Weight

• Approx. 91kg (including regular toner)

Print Specifications

Print Speed

• up to 60 ppm (A4, A5*, A5R, A6R*), up to 32 ppm (A3), up to 36 ppm (A4R)

* 1-sided only

Print Resolution (dpi)

• 1,200 x 1,200

Page Description Languages

• Standard: UFR II, PCL6
• Optional: Adobe® PostScript®3^TM

Direct Print

• Supported file types: PDF, EPS, TIFF/JPEG, and XPS

Mobile / Cloud Printing

• AirPrint, Mopria, Universal Print by Microsoft, Canon PRINT Business App, and uniFLOW Online (optional)
• A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
• Please contact your sales representative for further information.

OS Standard Printing

• Android/Windows® 10/Windows® 11/Chrome OS/macOS (11.2.2 or later)/iOS (15.2 or later)/iPadOS

Fonts

• PS fonts: 136 Roman
• PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T*1
  (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*2

*1 Optional PCL International Font Set-A1 is required.
*2 Optional Barcode Printing Kit-D1 is required.

Print Features

• Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced Hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer

Operating Systems

• UFRII: Windows® 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 2019/Server2022, Mac OS X (10.11 or later)
• PCL: Windows® 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 2019/Server2022
• PS: Windows® 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 2019/Server2022, Mac OS X (10.11 or later)
• PPD: Windows® 8.1/10/11, Mac OS X (10.11 or later)
• As of Jan. 2022

Copy Specifications

Copy Speed

• up to 60 ppm (A4, A5*, A5R, A6R*), up to 32 ppm (A3), up to 36 ppm (A4R)

* 1-sided only

First-Copy-Out Time

• Approx. 2.9 seconds or less

Copy Resolution (dpi)

• 600 x 600

Multiple Copies

• Up to 9,999 copies

Copy Density

• Automatic or Manual (9 Levels)

Magnification

• Variable zoom: 25% to 400% (1% Increments)
  Preset reduction/enlargement: 25%, 50%, 70%, 100% (1:1), 141%, 200%, 400%

Basic Copy Features

• Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Job Build, N on 1, Add Cover, Insert Sheets, Different Size Originals, Page Numbering, Copy Set Numbering, Sharpness, Erase Frame, Secure Watermark, Print Date, Gutter, Print & Check, Negative/Positive, Repeat Images, Merge Job Blocks, Mirror Image, Store in Mail Box, Superimpose Image, Copy ID Card, Skip Blank Pages, Free Size Original, Reserved copy, Copy Sample

Scan Specifications

Type

• Single-pass Duplexing Automatic Document Feeder* [2-sided to 2-sided (Automatic)]

* Multi-Sheet Feed Detection.

Pull Scan Specifications

• Colour Network ScanGear2. For both TWAIN and WIA
• Supported OS: Windows® 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server2019/Server2022
• As of Nov. 2021

Scan Resolution (dpi)

• Scan for Copy: 600 x 600
• Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
• Scan for Fax: 600 x 600

Document Feeder Paper Capacity (80 gsm)

• Up to 200 Sheets

Acceptable Originals/Weights

• Platen: Sheet, Book, and 3-Dimensional Objects
• Document Feeder media weight:
• 1-sided scanning: 38 to 220 gsm
• 2-sided scanning: 38 to 220 gsm

* An acceptable weights of A6R or smaller is 50 to 220gsm.

Supported Media Sizes

• Platen scanning size: up to 297.0 x 431.8 mm
• Document Feeder media size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6R
• Custom size: 70.0 x 139.7 mm to 304.8 x 431.8 mm

Scan Method

• Push Scan, Pull Scan, Scan to Box, Scan to Advanced Space, Scan to Network, Scan to USB Memory Key, Scan to Mobile devices, Scan to cloud (uniFLOW Online – Optional)

Scan Speed

• 1-sided Scanning: 135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy)
• 2-sided Scanning: 270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy)

Send Specifications

Destination

• Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV, Mail Box
• Optional: Super G3 FAX, IP Fax

Address Book / Speed Dials

• LDAP (2,000)/Local (1,600)/Speed dial (200)

Send Resolution (dpi)

• Push: up to 600 x 600
• Pull: up to 600 x 600

Communication Protocol

• File: FTP (TCP/IP), SMB3.0 (TCP/IP), WebDAV
• E-mail/I-Fax: SMTP, POP3

File Format

• TIFF, JPEG, PDF (Compact, Searchable, Apply policy, Optimise for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

Universal Send Features

• Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Copy Ratio, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Pages

Fax Specifications

Maximum Number of Connection Lines

• 1

Modem Speed

• Super G3: 33.6 kbps
  G3: 14.4 kbps

Compression Method

• MH, MR, MMR, JBIG

Resolution (dpi)

• 400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal)

Sending/Receiving Size

• Sending: A3, A4, A4R, A5*1, A5R*1, B4, B5*2, B5R*1
• Receiving: A3, B4, A4, A4R, A5R , B5, B5R

*1 Sent as A4
*2 Sent as B4 short

FAX Memory

• Up to 30,000 pages (2,000 jobs)

Speed Dials

• Max. 200

Group Dials/Destinations

• Max. 199 dials

Sequential Broadcast

• Max. 256 addresses

Memory Backup

• Yes

Fax Features

• Sender’s Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log

Store Specifications

Mail Box

• 100 User Inboxes
• 1 Memory RX Inbox
• 50 Confidential Fax Inboxes
• Maximum 30,000 Pages (2,000 jobs) Stored

Advanced Space

• Communication Protocol: SMB or WebDAV
• Supported Client PC: Windows® 8.1/10
• Concurrent Connections (Max.): SMB:64, WebDAV:3

Advanced Space Available Disk Space

• Standard:16 GB (With option: max. 480GB)

Advanced Space Features

• Authentication for Advanced Space Log-in, Sort Function, Printing a PDF File with a Password, imageWARE Secure Audit Manager Support, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore

Security Specifications

Authentication & Access Control

• User Authentication (Picture Login, Picture and PIN Login, Card Login*, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)* Card readers are optional, please refer to Hardware Accessories-Activation is required

Network Security

• TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), WPA3 support (Wi-Fi), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception

Document Security

• Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*1), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Space Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark)*1 Requires uniFLOW Online / uniFLOW

Device Security

• Protecting SSD Data [SSD Data Encryption (FIPS140-2 Validated), SSD Lock], Standard SSD Initialise, Trusted Platform Module (TPM 2.0), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runtime Intrusion Detection enabled with McAfee Embedded Control), HCD-PP*

* Certification will follow post launch of this Series

Device Management & Auditing

• Administrator Password, Digital Certificate And Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Environmental Specifications

Operating Environment

• Temperature: 10 to 30 ºC
• Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

• 220-240 V, 50/60 Hz, 6 A

Power Consumption

• Maximum: Approx. 1,800 W
• Copying (with DADF continuous scan): Approx. 858 W*1
• Standby: Approx. 50.7 W*1
• Sleep mode: Approx. 0.8 W*2

*1 Reference value: measured one unit

*2 0.8 W is not available in all circumstances due to certain settings.

• Typical Electricity Consumption (TEC): 0.71 kWh

* As per USA Energy Star 3.0

Noise Levels
